Inspection Robot

Self-propelled robotic system for visual diagnosis of drainage networks. Features a camera with integrated LED lighting and a robust wheeled-drive chassis, designed for environments with water and sediment.

Working diameter	DN100 – DN600 mm
Camera	HD Color, integrated LED lighting, real-time view
Viewing angle	120° horizontal
Protection rating	IP68 — submersible
Drive	Self-propelled chassis with drive wheels, 4WD
Max. speed	0–15 m/min (variable by control)
Max. cable length	150 m (extendable)
Operating temperature	0 °C – 50 °C
Software	Compatible with CCTV reporting software (EN 13508-2)
Manufacturing	Own design and production
Support	Own technical service — repair and replacement equipment

• ✓ Self-propelled chassis with wheel drive to advance through the pipe
• ✓ Camera with integrated LED lighting for real-time view
• ✓ Robust construction, IP68 submersible
• ✓ Compatible with reporting software to document each inspection
• ✓ Own design, manufacturing and technical support
• ✓ Own warranty and technical service — designed and supported by Otter Store
